GHOST KATO 20″ FULL PARTY

Kato 20 Full Party

Bike Geometry
Bottom bracket drop [mm]:
45 mm
Chain stay length [mm]:
362 mm
Head tube angle:
68 degrees
Head tube length [mm]:
110 mm
Reach [mm]:
280 mm
Stack [mm]:
455 mm
Stand over height [mm]:
473 mm
Seat tube angle:
69 degrees
Seat tube length [mm]:
250 mm
Top tube length [mm]:
437 mm
Wheelbase [mm]:
843 mm
Brake system
Brake Front Mount:
Post Mount
Brake Rear Mount:
Post Mount
Brake Front Description:
Tektro, Freno de disco hidráulico, HD-M276, 160 mm
Brake Rear Description:
Tektro, Freno de disco hidráulico, HD-M276, 160 mm
Drivetrain
Cassette Teeth:
11-42T
Crank Arm length:
114
Crankset Teeth:
28T
Crankset Type:
single
Number Of Gears:
10
Bottom Bracket Description:
Neco, BSA, B910-73, AXLE122
Cassette Description:
Shimano, Deore CS-M4100-10, HG
Chain Description:
KMC, X10
Crankset Description:
Samox, Square Taper alloy crankarm + chainring
Derailleur Rear Description:
Shimano, Deore RD-M6000 10s
Gear Description:
Shimano, Derailleur
Pedal Description:
VP, VPE-225
Shifter Right Description:
Shimano, Triggershift, Deore SL-M4100
Frame and more
Max loadable weight (KG):
60 kg
Front Fork Type:
Suspension
Front Fork Description:
Ghost, MTB Suspension 50 mm
Frame Description:
Kids, Aluminio, Mixto
Handlebar and Saddle
Handlebar Material:
Aluminio
Handlebar Rise:
25
Handlebar Width:
540 mm
Seatpost Material:
Aluminio
Stem Length:
40 mm
Handgrip Description:
Velo, VLG 1979-D
Handlebar Description:
Ghost, Flat bar, Junior
Headset Description:
Fsa, 1-1/8″ 50/44
Saddle Description:
Ghost, VL 5062
Seatpost Description:
Ghost, Non Suspension
Stem Description:
Ghost, Dia. 28.6 mm
Wheels and wheel components
Tamaño de la rueda en pul:
20
Hub Front Description:
Ghost, KT-T04F QR
Hub Rear Description:
Ghost, KT-MR5R QR
Rim Description:
Shining Rims, DB-X30
Rim Rear Description:
Shining Rims, DB-X30
Spoke Description:
Ghost, BCI SPOKE, 14G
Tyre Description:
Schwalbe, Smart Sam 2.35
Tyre Rear Description:
Schwalbe, Smart Sam 2.35
Wheelsize Description:
20
